Description
Tired of slow and heavy jacks? The AGM Manual Jack is The compact and lightweight solution. Its quick release height adjustment clamp lets you change the lift point on the fly. Its concave pad design prevents the pad from sinking in the sand, like other jacks. The modular mounting system, which locks the Jack to the vehicle, when using our Weld-On Jack Points, will give you confidence and peace of mind that whatever the trail throws at you, you'll fix it fast with the Manual Jack.
KEY FEATURES
- 3000lbs capacity
- 14in. travel
- 17in. external height adjustment
- Weighs 11 lbs.
- 27.5in. collapsed length (with pad folded for storage)
- No sink pad design
- Modular mounting system lets you use one of our lift adapters (Jack Points or Universal hook) or make your own.
- Patent No. 11,584,624
Additional Information
| Choose Included Lifting Options |
Universal Hook, Weld-On Jack Points |
|---|
Reviews
Customer Reviews
Based on 3 reviews
Write a review
F.A.Q.
I’M TRYING TO FIGURE OUT WHERE I CAN PUT THE MANUAL JACK. HOW LONG IS IT COLLAPSED?
The Manual Jack has a total length of 27.5 inches, end to end, with the pad at the bottom of the jack folded flat for storage.
HOW MUCH SPACE WILL I NEED TO MOUNT THE MANUAL JACK “WELD-ON RACE MOUNT KIT” (part#AGM-EJA-2020)?
You will need a total of 26 ⅝ in. of space to mount the “Weld-On Race Mount kit”. This is from the edge of the cup that locates the top of the Jack to the edge of the Lower mount that the Jack pad registers into. Please note this distance requires the Manual Jack to be fully collapsed when installed into the mount. Which is the ideal configuration when storing as it is the fastest and easiest to duplicate every time you are done using the Manual Jack and need to put it away.
I AM INSTALLING THE “WELD-ON RACE MOUNT KIT”, DOES THE LOWER MOUNT NEED TO BE POSITIONED IN A SPECIFIC WAY?
The lower mount (portion of the kit that holds the Manual Jack pad), should be mounted with the release pin easily accessible. This often means it is at the highest point and can be grabbed without having to reach around other components or the Manual Jack itself. The lower mount should also be positioned so that when in place, you can slide the top of the Jack into the cup (that comes with the kit) and then pivot the bottom of the Jack down into the lower mount. The release pin locking the Manual Jack into the mount when the Manual Jack is its final stored position. BE SURE TO READ THE INSTRUCTION THAT COME IN THE KIT FOR MORE DETAILS.
The Manual Jack has a total length of 27.5 inches, end to end, with the pad at the bottom of the jack folded flat for storage.
HOW MUCH SPACE WILL I NEED TO MOUNT THE MANUAL JACK “WELD-ON RACE MOUNT KIT” (part#AGM-EJA-2020)?
You will need a total of 26 ⅝ in. of space to mount the “Weld-On Race Mount kit”. This is from the edge of the cup that locates the top of the Jack to the edge of the Lower mount that the Jack pad registers into. Please note this distance requires the Manual Jack to be fully collapsed when installed into the mount. Which is the ideal configuration when storing as it is the fastest and easiest to duplicate every time you are done using the Manual Jack and need to put it away.
I AM INSTALLING THE “WELD-ON RACE MOUNT KIT”, DOES THE LOWER MOUNT NEED TO BE POSITIONED IN A SPECIFIC WAY?
The lower mount (portion of the kit that holds the Manual Jack pad), should be mounted with the release pin easily accessible. This often means it is at the highest point and can be grabbed without having to reach around other components or the Manual Jack itself. The lower mount should also be positioned so that when in place, you can slide the top of the Jack into the cup (that comes with the kit) and then pivot the bottom of the Jack down into the lower mount. The release pin locking the Manual Jack into the mount when the Manual Jack is its final stored position. BE SURE TO READ THE INSTRUCTION THAT COME IN THE KIT FOR MORE DETAILS.
The Manual Jack 2.0
$979.00
